Solar Power wall 48V 10KWH wall-mounted lithium iron phosphate battery for home storage solution with BMS
- 2022-11-23 -
|
Item name
|
Solar Power wall 48V 10KWH wall-mounted lithium iron phosphate battery for home storage solution with BMS
|
|
|
Rated voltage
|
51.2V
|
51.2V
|
|
Rated capacity
|
100Ah
|
200Ah
|
|
Max. Charging Current
|
50A
|
100A
|
|
Max. Discharging Current
|
100A
|
200A
|
|
Energy Capacity
|
5.12kWh
|
10.24kWh
|
|
Depth of Discharge (DoD)
|
100%
|
100%
|
|
Operating Voltage Range
|
43.2~57.6V
|
43.2~57.6V
|
|
Internal Resistance
|
≤ 20 mΩ
|
≤ 20 mΩ
|
|
Cycle Life
|
6000 times
|
6000 times
|
|
Scalability
|
max. 16 units in parallel
|
max. 16 units in parallel
|
|
Communication
|
CAN and RS-485 compatible (optional)
|
CAN and RS-485 compatible
|
|
System Weight
|
46kg
|
100kg
|
|
Dimension (W x D x H)
|
360*160*582mm
|
495*200*800mm
|
|
Warranty
|
10 years
|
10 years
|
|
IP Protection
|
IP65
|
IP65
|
|
Relative Humidity
|
15% ~ 85%
|
15% ~ 85%
|
Solar Power wall 48V 10KWH wall-mounted lithium iron phosphate battery for home storage solution with BMS
When the natural disaster coming, no electricity, will makes your life in trouble?
When the electricity bill higher and higher, will your life in trouble?
When there is no oil, no gas, how will you and your family live in the cold winter ?
………
The things changed so quickly, energy crisis is obviously, choose a replacement new energy is a trend.
Deligreen can help you for your home solar and energy storage system.
This is new launched model, 5.12KWH and 10.24KWH power wall, longer cycle life, safer grade A battery cells.
The batteryqueen wall mount battery pack can be as a good backup power, when natural disaster coming, you dont need to worry the Electricity, support max connecting 16P, 80KWH
Its helps you energy independence, cool!
